2G&4G long standby container GPS FM03G

FM03G is a 2G&4G tracker which is designed for container tracking, this unit is able to work for 3 to 5 years with 8100～10800mAh battery built in, It is widely used in highway container transportation and shipping。

Inquiry

Close

Applications

  • Functions
    Container vent window design； 3-5 years long standby; Position,AGPS/LBS; Battery Level Detect; Intelligent Tracking; Blind zone compensation; E-Sim(Optional Functions); Light Sensor(Optional Functions) Temperature and humidity detect(Optional Functions)

Specification

GSM frequency

2G:850/900/1800/1900 MHz
4G China/India TDD LTE:B38/B39/B40/B41
FDD LTE:B1/B3/B5/B8
WCDMA:B1/B8
GSM:900/1800MHz
Europe/Middle East/Africa TDD LTE:B38/B40/B41
FDD LTE:B1/B3/B5/B7/B8/B20
WCDMA:B1/B5/B8
GSM:B3/B8
North America FDD LTE:B2/B4/B5/B12/B13/B14
WCDMA:B2/B4/B5
Australia/Taiwan/Brazil FDD LTE:B1/B3/B4/B5/B7/B8/B28
WCDMA:B1/B2/B5/B8
GSM:B2/B3/B5/B

GPS chipset

MTK high sensitivity chip

GPS channel

66

Location accuracy

10 meters

Battery

Unchangeable 8100mAh Lithium battery
Optional 5400,10800mAh

Operating temperature

Minus 20 degrees to 70 Celsius

Device dimension

205mm*68mm*27mmuff08L*W*Huff09

Device weight

200gu00b15g

Waterproof

IP67

Protocol

TCP
